Endress+Hauser Vibronic Point level detection Soliphant FTM50-AGG2A2A12AA

Specs at a glance
Process temperature
-50°C ... 280°C
(-60°F ... 540°F)

Process pressure / max. overpressure limit
Vacuum ... 25 bar
(Vacuum ... 360 psi)

Min. density of medium
Standard fork: 10 g/l
Short fork: 50 g/l

Field of application
Soliphant FTM50 is a robust point level switch for use in silos containing fine-grained or powdery solids even with a low bulk density. Suitable for a wide range of applications with international certificates for use in dust or gas hazardous areas. Available with polished fork and stainless steel housing with Tri-Clamp or with aluminum housing and coated fork. Maintenance-free device for use in typical applications like: cereals, flour, cocoa, sugar, animal feed, dye powder, chalk.

Point level switch for fine grained solids and powder.

Process connections: Threads, flanges and hygienic connection (Tri-Clamp)

Temperature: -50 to +280°C (-60 to +540°F)

Pressure: -1 to +25bar (-14.5 to +360psi)

Sensor length: 145mm, 200mm

Sensor material: 316L (3,2µm, 0,8µm, PTFE coated, ETFE coated)

International explosion protection certificates

Benefits
SIL2 in accordance with IEC 61508

No mechanically moved parts, free of maintenance

Measurement not affected by build-up or external vibration

Various electronic inserts: e.g. NAMUR, relay, thyristor and PFM-signal outputs for optimum alignment with the plant control system

Build-up and abrasion display selectable, density setting and switching delay selectable

Choice of coated or polished sensor

Build-up and corrosion detection

Measuring principle
Vibration Solids

Characteristic / Application
Compact point level switch for fine grained solids and powder
Grain size
